DSTI
DSTI ESE2124 18-Channel Capsule Slip Ring
DSTI ESE2124 18-Channel Capsule Slip Ring
Regular price
CHF 1,499.00
Regular price
CHF 1,600.00
Sale price
CHF 1,499.00
Unit price
per
Tax included.
Couldn't load pickup availability
DSTI ESE2124 18-Channel Capsule Slip Ring
| Technical Specifications | |
| Model # | ESE2124 |
| Channels | 18 |
| Rated Current | (12x) 2A, (2x) 5A, (1x) Ethernet |
| Rated Voltage | 240V |
| Operating Temperature | -40° C to 80° C [-40° F to 176° F] |
| Maximum Speed | 250 RPM |
| Capsule Length | 1.950" [50 mm] |
| Lead Wire Length | 48" [1219 mm] |
| Max. Data Speed | 100 Mbps [100Base-T] |
| Contact Material | Gold |
| Wire Gauge (AWG) / Material | 26, 28 / Silver-Plated Copper |
| Electrical Noise | 60 Milliohms (max.) |
