ESM428 32-Channel Capsule Slip Ring - DSTI
| Technical Specifications | |
| Model # | ESM428 |
| Channels | 32 |
| Rated Current | (4x) 5A, (28x) 2A |
| Rated Voltage | 240V |
| Operating Temperature | -40° C to 80° C [-40° F to 176° F] |
| Maximum Speed | 250 RPM |
| Capsule Length | 2.600" [66 mm] |
| Lead Wire Length | 48" [1219 mm] |
| Max. Data Speed | Under 50 Mbps [Non-Ethernet] |
| Contact Material | Gold |
| Wire Gauge (AWG) / Material | 16, 20 / Silver-Plated Copper |
| Electrical Noise | 60 Milliohms (max.) |
