Gigavac G43A334 10kV SPST-NO HV Relay

Gigavac G43A334 10kV SPST-NO HV Relay

Specifications
Voltage Rating	10kV
Rated Voltage (KV Peak) DC or 60Hz	5
Coil Voltage	26.5VDC
Coil Connection	solder - bus wire
Form	SPST-NO
High Voltage Connection	solder tabs
Download	Download



G43A334 Model Selection Table

G43A	3	3	4
High Voltage/ Power Terminal Connections	2 = 12 Vdc, Bus Wire 3 = 26.5 Vdc, Bus Wire 5 = 115 Vdc, Bus Wire 7 = 12 Vdc, Turret Terminal 8 = 26.5 Vdc, Turret Terminal 9 = 115 Vdc, Turret Termina
Mounting		3 = Solder Connection
Coil Voltage			2 = 3-hole Flange 4 = Std Flange
